Micrometers

ACCUD 347 Sheet metal micrometer

ACCUD 347 Sheet metal micrometer — Image from the catalogue, page 119

347

This product is part of the full ACCUD range. Send an inquiry for versions, specifications and prices. We reply within 4 business days.

Inquiry Add to inquiry View in the catalogue (PDF), p. 119

Versions from the catalogue 3

(dimensions in mm)

Code	Range	Accuracy	a	h	L	Add
347-015-01	0-15mm	4μm	8	50	22	+ Add
347-001-01	0-25mm	4μm	8	50	32	+ Add
347-002-01	0-50mm	5μm	12	100	57	+ Add

Data output
For measuring tube thickness, shoulder edge distance, rivet head height, etc.
Supplied with flat anvil and rod anvil
Resolution: 0.001mm/0.00005"
IP65 dust and water protection
Buttons: on/off, set, mm/inch

Page 119 of the ACCUD catalogue with the dimension drawing and full data — Page 119 of the ACCUD catalogue with the dimension drawing and full data (PDF)
