ACCUD 328 Spline micrometer
328
This product is part of the full ACCUD range. Send an inquiry for versions, specifications and prices. We reply within 4 business days.
Versions from the catalogue 8
(dimensions in mm)
| Code | Range | Anvil | Accuracy | h | L | Setting standards (included) | Add |
|---|---|---|---|---|---|---|---|
| 328-001-03 | 0-25mm | B | 4μm | 39 | 58 | - | + Add |
| 328-002-03 | 25-50mm | B | 4μm | 53 | 83 | 25mm | + Add |
| 328-003-03 | 50-75mm | B | 5μm | 65 | 109 | 50mm | + Add |
| 328-004-03 | 75-100mm | B | 5μm | 76 | 133 | 75mm | + Add |
| 328-005-03 | 100-125mm | B | 6μm | 82 | 158 | 100mm | + Add |
| 328-006-03 | 125-150mm | B | 6μm | 94.5 | 183.4 | 125mm | + Add |
| 328-007-03 | 150-175mm | B | 7μm | 107 | 208.8 | 150mm | + Add |
| 328-001-04 | 0-25mm | A | 4μm | 39 | 58 | - | + Add |
- Graduation: .0001" (within 12"), .001" (over 12")
- Ratchet stop
- Carbide measuring faces
- Supplied with setting standards
- Interchangeable anvils included
