Micrometers

ACCUD 308 Large anvil micrometer

308

This product is part of the full ACCUD range. Send an inquiry for versions, specifications and prices. We reply within 4 business days.

Versions from the catalogue 2

(dimensions in mm)

Code	Range	Accuracy	a	h	L	Add
308-001-01	0-25mm	4µm	50	26	42	+ Add
308-002-01	25-50mm	4µm	60	38	67	+ Add

For measuring diameters of parts or cutting tools with an odd number of grooves (taps, reamers, end mills)
Graduation: 0.01mm
Ratchet stop
Carbide measuring faces
